Solutions for special requirements
Architecture is diverse. Stringent requirements in terms of technology and outstanding design are making architecture increasingly complex. Individual solutions are key here for special requirements. SIMONSWERK therefore offers a variety of special hinge systems to give every room the right presence.
Products for special requirements
With a welded hinge knuckle, the hinge system for heavy-duty doors is suitable for timber, steel and aluminium frames. So even the most demanding requirements for fire and smoke protection and soundproofing can be met.
- for rebated and unrebated heavy-duty doors
- load capacity 400 kg
- for blind, block and casing frames
- optional receiving groove for continuous acoustic seal
- for 3D-adjustable VARIANT VX receivers
- with internal torsion-proof pin
- maintenance-free axial-radial slide bearings
With the special VARIANT Care hinge system, planned frame rebate dimensions are turned into real clearance dimensions, as the door can be completely opened at a 90° angle. The hinge systems from the product range are optimised for door leaf thicknesses from 40 to 70 mm.
- for unrebated heavy-duty doors
- for timber, steel and aluminium frames
- for load capacities up to 100 kg
- for 3D-adjustable VARIANT VX receivers
- for door thicknesses of 40 mm, 45 mm, 50 mm, 65 mm and 70 mm
- with internal torsion-proof pin
- maintenance-free axial-radial slide bearings
For unrebated doors with a finger protection function on timber, steel and aluminium frames
- for load capacities up to 120 kg
- continuous finger protection on the secondary closing edge
- for use in new builds and renovations
- maintenance-free running on steel balls
- consisting of frame part VN 7100 finger protection and door part VN 0099 finger protection incl. receivers VN 7507 3D
Providing adjustable hinge solutions, VARIANT Compact is highly suited to elegant frame views. By offsetting the hinge receiver in the door leaf, pre-existing steel frames etc. can be renovated in a way that saves time and money
- adjustable receiver in the door leaf
- comfortable 3D adjustment for slim frame constructions
- for load capacities up to 200 kg
- alternative model variants with reduced, elegant knuckles
- suitable for functional doors with smoke and fire protection
The VARIANT VX 7729/160-4 HA MSTS hinge system was specially developed for entrance doors made from timber and aluminium and is based on the tried-and-tested VARIANT VX knuckle hinge technology.
- compact unit consisting of knuckle hinge, receiver and cover angle
- for load capacities up to 160 kg
- for 3D-adjustable receivers VX 7531 3D and VX 7535 3D
- comes with security pin and welded hinge knuckle
- concealed axial-radial slide bearing
This hinge system features reduced, elegant knuckle and excels with its linear shapes and a reduced yet sturdy construction, integrating seamlessly into sophisticated architecture.
- elegant knuckle reduced in diameter
- for slim, recessed frame facings
- for load capacities up to 160 kg
- CE-certified
- suitable for fire and smoke protection
Das VARIANT Nachrüst-Kit sowie unterschiedliche Nach- und Umrüstutensilien bieten vielfältige Möglichkeiten Bandsysteme an vorhandenen Türen zu korrigieren und zu stabilisieren
- zum Verstärken oder Ersetzen des vorhandenen Bandsystems an Holz- oder Glastüren
- Stabilisierung der Zargenanbindung von Tür und Band bei Glastüren
- einfache Lösungen zur nachträglichen Korrektur des Türsitzes
- vielfältige Befestigungssets
By offsetting the hinge receiver in the door leaf, existing frames can be continued to be used in a way that saves time and money and the door element can be fitted with modern hinge technology.
- offsetting the hinge receiver in the door leaf
- using modern hinge systems even in old frames
- load capacity up to 160 kg
- cost-effective and time-saving
